CF 無直部大小頭
CF ZERO LENGTH REDUCERS
材質：304/L
Catalogue PN
Large Flange
Small Flange
Tube Size
B
(mm)D
(mm)CF-ZL-212x133N
CF2.12" Tapped holes
CF1.33" Tapped holes
3/4"
15.75
11.90
CF-ZL-275x133Z
CF2.75" Thru holes
CF1.33" Tapped holes
3/4"
15.75
12.70
CF-ZL-275x212N
CF2.75" Tapped holes
CF2.12" Tapped holes
1.0"
25.40
12.70
CF-ZL-338x133Z
CF3.38" Thru holes
CF1.33" Tapped holes
3/4"
15.75
16.00
CF-ZL-338x212Z
CF3.38" Thru holes
CF2.12" Tapped holes
1.0"
25.40
16.00
CF-ZL-338x275N
CF3.38" Tapped holes
CF2.75" Tapped holes
1.5"
38.10
16.00
CF-ZL-450x133Z
CF4.50" Thru holes
CF1.33" Tapped holes
3/4"
15.75
17.40
CF-ZL-450x212Z
CF4.50" Thru holes
CF2.12" Tapped holes
1.0"
25.40
17.40
CF-ZL-450x275Z
CF4.50" Thru holes
CF2.75" Tapped holes
1.5"
38.10
17.40
CF-ZL-450x338N
CF4.50" Tapped holes
CF3.38" Tapped holes
2.0"
50.80
17.40
CF-ZL-462x133Z
CF4.62" Thru holes
CF1.33" Tapped holes
3/4"
15.75
19.10
CF-ZL-462x212Z
CF4.62" Thru holes
CF2.12" Tapped holes
1.0"
25.40
19.10
CF-ZL-462x275Z
CF4.62" Thru holes
CF2.75" Tapped holes
1.5"
38.10
19.10
CF-ZL-462x338Z
CF4.62" Thru holes
CF3.38" Tapped holes
2.0"
50.80
19.10
CF-ZL-600x133Z
CF6.00" Thru holes
CF1.33" Tapped holes
3/4"
15.75
19.80
CF-ZL-600x212Z
CF6.00" Thru holes
CF2.12" Tapped holes
1.0"
25.40
19.80
CF-ZL-600x275Z
CF6.00" Thru holes
CF2.75" Tapped holes
1.5"
38.10
19.80
CF-ZL-600x338Z
CF6.00" Thru holes
CF3.38" Tapped holes
2.0"
50.80
19.80
CF-ZL-600x450Z
CF6.00" Thru holes
CF4.50" Tapped holes
2.5"
63.50
19.80
CF-ZL-600x462N
CF6.00" Tapped holes
CF4.62" Tapped holes
3.0"
76.20
19.80
CF-ZL-675x275Z
CF6.75" Thru holes
CF2.75" Tapped holes
1.5"
38.10
21.34
CF-ZL-675x450Z
CF6.75" Thru holes
CF4.50" Tapped holes
2.5"
63.50
21.34
CF-ZL-800x133Z
CF8.00" Thru holes
CF1.33" Tapped holes
3/4"
15.75
22.35
CF-ZL-800x275Z
CF8.00" Thru holes
CF2.75" Tapped holes
1.5"
38.10
22.35
CF-ZL-800x450Z
CF8.00" Thru holes
CF4.50" Tapped holes
2.5"
63.50
22.35
CF-ZL-800x600Z
CF8.00" Thru holes
CF6.00" Tapped holes
4.0"
101.60
22.35
CF-ZL-1000x133Z
CF10.00" Thru holes
CF1.33" Tapped holes
3/4"
15.75
24.60
CF-ZL-1000x275Z
CF10.00" Thru holes
CF2.75" Tapped holes
1.5"
38.10
24.60
CF-ZL-1000x450Z
CF10.00" Thru holes
CF4.50" Tapped holes
2.5"
63.50
24.60
CF-ZL-1000x600Z
CF10.00" Thru holes
CF6.00" Tapped holes
4.0"
101.60
24.60
CF-ZL-1000x800Z
CF10.00" Thru holes
CF8.00" Tapped holes
6.0"
152.40
24.60
CF-ZL-1325x133Z
CF13.25" Thru holes
CF1.33" Tapped holes
3/4"
15.75
28.45
CF-ZL-1325x275Z
CF13.25" Thru holes
CF2.75" Tapped holes
1.5"
38.10
28.45
CF-ZL-1325x450Z
CF13.25" Thru holes
CF4.50" Tapped holes
2.5"
63.50
28.45
CF-ZL-1325x600Z
CF13.25" Thru holes
CF6.00" Tapped holes
4.0"
101.60
28.45
CF-ZL-1325x800Z
CF13.25" Thru holes
CF8.00" Tapped holes
6.0"
152.40
28.45
CF-ZL-1325x1000Z
CF13.25" Thru holes
CF10.00" Tapped holes
8.0”
203.20
28.45
